GE 350

3-20 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
DNP ETHERNET PROTOCOL SETTINGS CHAPTER 3: ETHERNET INTERFACE
To support existing SCADA hardware not capable of 32-bit data reads, the upper and lower
16-bit portions of the fault report time and date values have been assigned to separate
points. To read a date or time, it is necessary to read both the upper and lower 16-bit
portions, concatenate these two values to form a 32-bit value and interpret the result in
the format associated with the point.
Fault Report Mapping 350 and 339 Fault Report Mapping 345
Disabled Enabled Disabled Enabled
- 0 Fault Report Date Upper 16 - 0 Fault Report Date Upper 16
- 1 Fault Report Date Lower 16 - 1 Fault Report Date Lower 16
- 2 Fault Report Time Upper 16 - 2 Fault Report Time Upper 16
- 3 Fault Report Time Lower 16 - 3 Fault Report Time Lower 16
- 4 Fault Report Fault Type - 4 Fault Report Fault Type
- 5 Fault Report Ia - 5 Fault Report Ia
- 6 Fault Report Ia Angle - 6 Fault Report Ia Angle
- 7 Fault Report Ib - 7 Fault Report Ib
- 8 Fault Report Ib Angle - 8 Fault Report Ib Angle
- 9 Fault Report Ic - 9 Fault Report Ic
- 10 Fault Report Ic Angle - 10 Fault Report Ic Angle
- 11 Fault Report Ig - 11 Fault Report Ig
- 12 Fault Report Ig Angle - 12 Fault Report Ig Angle
- 13 Fault Report In - 13 Fault Report In
- 14 Fault Report In Angle - 14 Fault Report In Angle
- 15 Fault Report Va - 15 Fault Report System Frequency
- 16 Fault Report Va Angle - 16 Fault Report Ia 2
- 17 Fault Report Vb - 17 Fault Report Ia 2 Angle
- 18 Fault Report Vb Angle - 18 Fault Report Ib 2
- 19 Fault Report Vc - 19 Fault Report Ib 2 Angle
- 20 Fault Report Vc Angle - 20 Fault Report Ic 2
- 21 Fault Report Vab - 21 Fault Report Ic 2 Angle
- 22 Fault Report Vab Angle - 22 Fault Report Ig 2
- 23 Fault Report Vbc - 23 Fault Report Ig 2 Angle
- 24 Fault Report Vbc Angle - 24 Fault Report In 2
- 25 Fault Report Vca - 25 Fault Report In 2 Angle
- 26 Fault Report Vca Angle - 26 Fault Report Idiff 1 PhA
- 27 Fault Report Vn - 27 Fault Report Idiff 1 PhA Angle
- 28 Fault Report Vn Angle - 28 Fault Report I Restraint PhA
- 29 Fault Report Vaux - 29 Fault Report I Restraint PhA Angle
- 30 Fault Report Vaux Angle - 30 Fault Report Idiff 1 PhB
- 31 Fault Report System Frequency - 31 Fault Report Idiff 1 PhB Angle
- 32 Fault Report Phases - 32 Fault Report I Restraint Ph B
0 33 Analog Input Point 0 Entry - 33 Fault Report I Restraint PhB Angle
1 34 Analog Input Point 1 Entry - 34 Fault Report Idiff 1 PhC
… … … - 35 Fault Report Idiff 1 PhC Angle
… … … - 36 Fault Report I Restraint PhC
31 64 Analog Input Point 31 Entry - 37 Fault Report I Restraint PhC Angle
- 38 Fault Report Phases
0 39 Analog Input Point 0 Entry
