GE 350

A–6 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
instPDIF: Transformer Instantaneous Differential
rgfPDIF: Restricted Ground Fault Differential
2.2.2 PDOP (Directional Overpower)
PDOP: Directional overpower
PDIF class
Attribute Name Attr. Type Explanation M/O/C/E Notes
InstPDIF Overpower
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M XRFM INST DIFF PKP
Op ACT_2 Operate M XRFM INST DIFF OP
Blk ACT_3 Block E XRFM INST DIFF BLK
PDIF class
Attribute Name Attr. Type Explanation M/O/C/E Notes
RgfPDIF Overpower
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M RESTD GND FAULT PKP
Op ACT_2 Operate M RESTD GND FAULT OP
Blk ACT_3 Block E RESTD GND FAULT BLK
PDOP class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PDOP Overpower
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Directional Power PKP
Op ACT_2 Operate M Directional Power OP
Blk ACT_3 Block E Directional Power BLK
