GE 350

A–10 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
2.2.5 PMRI (Motor restart inhibition)
PMRI: Motor restart inhibition
2.2.6 PTOC (Time overcurrent)
phsPTOC: Phase TOC
ndPTOC: neutral TOC
PMRI class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PMRI Motor restart inhibition
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Strlnh SPS_0 Restart inhibited O
PTOC class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PhsPTOC Time overcurrent
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_0 Start O Phase TOC PKP
Op ACT_0 Operate M Phase TOC OP
Blk ACT_3 Block E Phase TOC BLK
PTOC class
Attribute Name Attr. Type Explanation M/O/C/E Notes
NdPTOC Time overcurrent
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_1 Start O Neutral TOC PKP
Op ACT_1 Operate M Neutral TOC OP
Blk ACT_3 Block E Neutral TOC BLK
