A–12 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
NgSeqPTOC: Negative Sequence TOC(345)
jamPTOC: Mechanical Jam
unbalPTOC: Current unbalanced
PTOC class
Attribute Name Attr. Type Explanation M/O/C/E Notes
NgSeqPTOC_1 Time overcurrent
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_1 Start O Negative Sequence TOC
PKP
Op ACT_1 Operate M Negative Sequence TOC OP
Blk ACT_3 Block E Negative Sequence TOC
BLK
PTOC class
Attribute Name Attr. Type Explanation M/O/C/E Notes
jamPTOC Time overcurrent
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_1 Start O Mechanical Jam PKP
Op ACT_1 Operate M Mechanical JamOP
Blk ACT_3 Block E Mechanical Jam BLK
PTOC class
Attribute Name Attr. Type Explanation M/O/C/E Notes
unbalPTOC Time overcurrent
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_1 Start O Current unbal PKP
Op ACT_1 Operate M Current unbal OP
Blk ACT_3 Block E Current unbal BLK
