A–14 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
2.2.8 PTOV (Overvoltage)
phsPTOV: phase overvoltage
auxPTOV: auxiliary overvoltage
ndPTOV: neutral overvoltage
PTOV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PhsPTOV Overvoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_0 Start M Phase TOV PKP
Op ACT_0 Operate M Phase TOV OP
Blk ACT_3 Block E Phase TOV BLK
PTOV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
AuxPTOV Overvoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Auxiliary PTOV PKP
Op ACT_2 Operate M Auxiliary PTOV OP
Blk ACT_3 Block E Auxiliary PTOV BLK
PTOV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
NdPTOV Overvoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Neutral TOV PKP
Op ACT_2 Operate M Neutral TOV OP
Blk ACT_3 Block E Neutral TOV BLK
