GE 350

A–18 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
2.2.12 PTUV (Undervoltage)
phsPTUV: phase undervoltage
auxPTUV: auxiliary undervoltage
psseqPTUV: positive sequence undervoltage
PTUV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PhsPTUV Undervoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_0 Start M Phase PTUV PKP
Op ACT_0 Operate M Phase PTUV OP
Blk ACT_3 Block E Phase PTUV BLK
PTUV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
AuxPTUV Undervoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Auxiliary UV PKP
Op ACT_2 Operate M Auxiliary UV OP
Blk ACT_3 Block E Auxiliary UV BLK
PTUV class
Attribute Name Attr. Type Explanation M/O/C/E Notes
PsSeqPTUV Undervoltage
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Status Information
Str ACD_2 Start M Positive Seq UV PKP
Op ACT_2 Operate M Positive Seq UV OP
Blk ACT_3 Block E Positive Seq UV BLK
