GE 350

A–28 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
MICS
MMXU1: W1 Phase currents (345).
MMXU2: W2 Phase currents(345).
MMXU3: Idiff 1 Phase Currents (345)
MMXU class
Attribute Name Attr. Type Explanation M/O/C/E Notes
MMXU_1 Measurement
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
A WYE_1 Phase currents (IL1, ...) O W1 Phase currents
MMXU class
Attribute Name Attr. Type Explanation M/O/C/E Notes
MMXU_1 Measurement
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
A WYE_1 Phase currents (IL1, ...) O W2 Phase currents
MMXU class
Attribute Name Attr. Type Explanation M/O/C/E Notes
DiffMMXU Measurement
Data
Common Logical Node Information
Mod INC_0 Mode M
Beh INS_0 Behaviour M
Health INS_1 Health M
NamPlt LPL_1 Name plate M
Measured values
A WYE_2 Phase currents (IL1, ...) O Idiff 1 Phase Currents
