GE 350

3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE A–43
3.2.3 Phase to ground related measured values of a three phase system ( WYE )
CMV_3
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
DataAttribute
measured attributes
cVal FloatVector MX dchg M
mag FloatAnalogueValue
f FLOAT32
q BVstring13 MX qchg M
t Utctime MX M
configuration, description and extension
units Unit CF O
SIUnit Byte M
Multiplier Byte O
d Vstring255 DC O
dataNs Vstring255 EX GE Multilin SR3
Namespace:2003
AC_DLN_M
WYE_0
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
WYE_1
Attribute Name Attribute Type FC TrgOp Value/Value Range M/O/C/E
Data
phsA CMV_0 GC_1
phsB CMV_0 GC_1
phsC CMV_0 GC_1
neut CMV_0 GC_1
net CMV_0 GC_1
res CMV_0 GC_1
configuration, description and extension
d Vstring255 DC O
