A–48 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
TICS
TICS
This section contains the TISSUES (Technical Issues) Implementation Conformance
Statement (TICS) for the IEC 61850 interface in the 3 Series Family of protective relays.
Date: January 3, 2017
Version 1.10
1 Introduction
This tissues conformance statement is applicable to the 3 Series family with firmware
version 2.30.
2 Implemented IntOp TISSUES
During the October 2006 meeting IEC TC57 working group 10 decided that:
• green Tissues with the category "IntOp" are mandatory for IEC 61850 edition 1
• Tissues with the category "Ed.2" Tissues should not be implemented.
Mandatory Edition 1 Tissues
The following table gives an overview of the implemented mandatory Tissues.
Part Tissue
Nr
Description Implemented
Y/na
8-1 116 GetNameList with empty response? Y
165 Improper Error Response for GetDataSetValues Y
183 GetNameList error handling Y
226 Control negative response (SBOns) with LastApplError na
545 Skip file directories with no files na
7-4 252 AlmThm should have CDC SPS na
7-3 28 Definition of APC na
54 Point def xVal, not cVal na
55 Ineut = Ires ? Y
63 mag in CDC CMV Y
65 Deadband calculation of a Vector and trigger option Y
219 operTm in ACT na
270 WYE and DEL rms values na
1199 BCR na
7-2 30 control parameter T na
31 Typo na
32 Typo in syntax na
35 Typo Syntax Control time na
36 Syntax parameter DSet-Ref missing na
37 Syntax GOOSE "T" type Y
39 Add DstAddr to GoCB Y
40 GOOSE Message "AppID" to "GoID "Y
41 GsCB "AppID" to "GsID "na
42 SV timestamp: "EntryTime" to "TimeStamp "na
