GE 350

A–56 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PICS
S24 1,2 Report TP Y
S24-1 1,2 data-
change
(dchg)
Y
S24-2 1,2 quality-
change
(qchg)
N
S24-3 1,2 data-update
(dupd)
N
S25 1,2 Ge t B R C B V a l u e s TP Y
S26 1,2 SetBRCBValues TP Y
Unbuffered report control block (URCB)
S27 1,2 Report TP Y
S27-1 1,2 data-
change
(dchg)
Y
S27-2 1,2 quality-
change
(qchg)
N
S27-3 1,2 data-update
(dupd)
N
S28 1,2 Ge t U R C B V a l u e s TP Y
S29 1,2 SetURCBValues TP Y
Logging
Log control
S30 1,2 Ge t L C B V a l u e s TP N
S31 1,2 SetLCBValues TP N
Log
S32 1,2 QueryLogByTime TP N
S33 1,2 QueryLogAfter TP N
S34 1,2 GetLogStatusValues TP N
Generic substation event model (GSE)
GOOSE
S35 1,2 SendGOOSEMessage MC Y
GOOSE Control Block
S36 1,2 GetGoReference TP
S37 1,2 GetGOOSEElementNumber TP
S38 1,2 Ge t G o C B V a l u e s TP Y
S39 1,2 SetGoCBValues TP Y
GSSE (Ed2:61850-7-2 Annex C)
S40 1,2 SendGSSEMessage MC N Deprecated in Edition 2
GSSE Control
Block (Ed2:61850-7-2 Annex C)
S41 1,2 GetGsReference TP N Deprecated in Edition 2
S42 1,2 GetGSSEDataOffset TP N Deprecated in Edition 2
S43 1,2 Ge t Gs C B V a l u e s TP N Deprecated in Edition 2
S44 1,2 SetGsCBValues TP N Deprecated in Edition 2
Ed ACSI Service AA:
TP/MC
Client Sub
(C)
Server Pub
(S)
Comments
