GE 469

112 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
F106
Unsigned
16 bit integer
VOLTAGE TRANSFORMER
CONNECTION TYPE
0None
1Open Delta
2Wye
F107
Unsigned
16 bit integer
NOMINAL FREQUENCY
060 Hz
150 Hz
2 Variable
F108
Unsigned
16 bit integer
REDUCED VOLTAGE STARTING
TRANSITION ON
0 Current Only
1 Current or Timer
2 Current and Timer
F109
Unsigned
16 bit integer
STARTER STATUS SWITCH
0 Starter Aux a
1 Starter Aux b
F110
Unsigned
16 bit integer
ASSIGNABLE INPUT FUNCTION
0Off
1 Remote Alarm
2 Remote Trip
3 Speed Switch Trip
4 Load Shed Trip
5Pressure Sw. Alarm
6 Pressure Switch Trip
7Vibration Sw. Alarm
8 Vibration Sw. Trip
9 Digital Counter
10 Tachometer
F110
ctd.t
11 General Sw. A
12 General Sw. B
13 General Sw. C
14 General Sw. D
15 Capture Trace
16 Simulate Pre-Fault
17 Simulate Fault
18 Simulate Pre-Fault...Fault
F111
Unsigned
16 bit integer
TRIP RELAYS
0Trip
1Trip & Aux2
2 Trip & Aux2 & Aux3
3Trip & Aux3
F112
Unsigned
16 bit integer
NOT DEFINED
0
1
Table 8: Data Formats (Sheet 4 of 15)
CODE TYPE DEFINITION
