GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 113
F113
Unsigned
16 bit integer
ALARM RELAYS
0Alarm
1Alarm & Aux2
2Alarm & Aux2 & Aux3
3Alarm & Aux3
4Aux2
5Aux2 & Aux3
6Aux3
7None
F114
Unsigned
16 bit integer
COUNTER TYPE
0 Increment
1Decrement
F115
Unsigned
16 bit integer
ALARM / TRIP TYPE SELECTION
0Off
1Latched
2Unlatched
F116
Unsigned
16 bit integer
SWITCH TYPE
0 Normally Open
1 Normally Closed
F117
Unsigned
16 bit integer
RESET MODE
0 All Resets
1 Remote Reset Only
2Keypad Reset Only
F118
Unsigned
16 bit integer
TRIP RELAYS
0Trip
1Trip & Aux2
2 Trip & Aux2 & Aux3
3Trip & Aux3
4Aux2
F118
ctd.
5Aux2 & Aux3
6Aux3
F119
Unsigned
16 bit integer
BACKUP RELAYS
0Aux2
1Aux2 & Aux3
2Aux3
F120
Unsigned
16 bit integer
RTD TYPE
0100 Ohm Platinum
1120 Ohm Nickel
2100 Ohm Nickel
310 Ohm Copper
Table 8: Data Formats (Sheet 5 of 15)
CODE TYPE DEFINITION
