114 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
F121
Unsigned
16 bit integer
RTD APPLICATION
0None
1Stator
2Bearing
3Ambient
4Other
F122
Unsigned
16 bit integer
RTD VOTING SELECTION
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
7RTD #7
8RTD #8
9RTD #9
10 RTD #10
11 RTD #11
12 RTD #12
F123
Unsigned
16 bit integer
ALARM STATUS
0Off
1Not Active
2 Timing Out
3Active
4Latched
F124
Unsigned
16 bit integer
PHASE ROTATION AT MOTOR
TERMINALS
0ABC
1ACB
F125
Unsigned
16 bit integer
STARTER TYPE
0Breaker
1 Contactor
F126
Unsigned
16 bit
DISABLED / ENABLED SELECTION
0 Disabled
1Enabled
Table 8: Data Formats (Sheet 6 of 15)
CODE TYPE DEFINITION
