GE 469

116 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
F128
Unsigned
16 bit int.
PROTECTION CURVE STYLE
SELECTION
0Standard
1Custom
2Voltage Dependent
F129
Unsigned
16 bit integer
ANALOG INPUT SELECTION
0 Disabled
14-20 mA
20-20 mA
30-1 mA
F130
Unsigned
16 bit integer
PICKUP TYPE
0Over
1Under
F131
Unsigned
16 bit integer
INPUT SWITCH STATUS
0Open
1Shorted
F132
Unsigned
16 bit integer
TRIP COIL SUPERVISION STATUS
0No Coil
1Coil
F133
Unsigned
16 bit integer
MOTOR STATUS
0Stopped
1Starting
2 Running
3Overloaded
4Tripped
Table 8: Data Formats (Sheet 8 of 15)
CODE TYPE DEFINITION
