GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 117
F134
Unsigned
16 bit integer
CAUSE OF EVENT /
CAUSE OF LAST TRIP (UP TO 49)
0No Event/Trip To Date
1 Incomplete Seq Trip
2 Remote Trip
3 Speed Switch Trip
4 Load Shed Trip
5Pressure Sw. Trip
6 Vibration Sw. Trip
7Tachometer Trip
8 General Sw. A Trip
9 General Sw. B Trip
10 General Sw. C Trip
11 General Sw. D Trip
12 Overload Trip
13 Short Circuit Trip
14 Short Circuit Backup
15 Mechanical Jam Trip
16 Undercurrent Trip
17 Current U/B Trip
18 Ground Fault Trip
19 Ground Fault Backup
20 Differential Trip
21 Acceleration Trip
22 RTD 1 Trip
23 RTD 2 Trip
24 RTD 3 Trip
25 RTD 4 Trip
26 RTD 5 Trip
27 RTD 6 Trip
28 RTD 7 Trip
29 RTD 8 Trip
30 RTD 9 Trip
31 RTD 10 Trip
32 RTD 11 Trip
33 RTD 12 Trip
34 Undervoltage Trip
35 Overvoltage Trip
Table 8: Data Formats (Sheet 9 of 15)
CODE TYPE DEFINITION
