GE 469

118 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
F134
ctd.
36 Phase Reversal Trip
37 Volt. Frequency Trip
38 Power Factor Trip
39 Reactive Power Trip
40 Underpower Trip
41 Analog I/P 1 Trip
42 Analog I/P 2 Trip
43 Analog I/P 3 Trip
44 Analog I/P 4 Trip
45 Single Phasing Trip
46 Reverse Power Trip
47
Field Circuit Open Trip (Valid only for
Mod 001)
48 Analog Diff 1-2 Trip
49 Analog Diff 3-4 Trip
50 ----
51 Remote Alarm
52 Pressure Sw. Alarm
53 Vibration Sw. Alarm
54 Counter Alarm
55 Tachometer Alarm
56 General Sw. A Alarm
57 General Sw. B Alarm
58 General Sw. C Alarm
59 General Sw. D Alarm
60 Thermal Model Alarm
61 Overload Alarm
62 Undercurrent Alarm
63 Current U/B Alarm
64 Ground Fault Alarm
65 RTD 1 Alarm
66 RTD 2 Alarm
67 RTD 3 Alarm
68 RTD 4 Alarm
69 RTD 5 Alarm
70 RTD 6 Alarm
71 RTD 7 Alarm
72 RTD 8 Alarm
73 RTD 9 Alarm
74 RTD 10 Alarm
75 RTD 11 Alarm
76 RTD 12 Alarm
77 Open RTD Alarm
78 Short/Low RTD Alarm
Table 8: Data Formats (Sheet 10 of 15)
CODE TYPE DEFINITION
