GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 119
F134
ctd.
79 Undervoltage Alarm
80 Overvoltage Alarm
81 Volt. Frequency Alarm
82 Power Factor Alarm
83 Reactive Power Alarm
84 Underpower Alarm
85 Trip Counter Alarm
86 Starter Failed Alarm
87 Current Demand Alarm
88 kW Demand Alarm
89 kvar Demand Alarm
90 kVA Demand Alarm
91
92 Analog I/P 1 Alarm
93 Analog I/P 2 Alarm
94 Analog I/P 3 Alarm
95 Analog I/P 4 Alarm
96 Reverse Power Alarm
97
Incomplete Seq Alarm
(Valid only for Mod 001)
98 Analog Diff 1-2 Alarm
99 Analog Diff 3-4 Alarm
100 Self-test Warning 9
101 Service Alarm
102 Control Power Lost
103 Cont. Power Applied
104 Emergency Rst. Close
105 Emergency Rst. Open
106 Start While Blocked
107 Relay Not Inserted
108 Trip Coil Super.
109 Breaker Failure
110 Welded Contactor
111 Simulation Started
112 Simulation Stopped
↓↓
118 Digital Trace Trigger
119 Serial Trace Trigger
120 RTD 1 High Alarm
121 RTD 2 High Alarm
122 RTD 3 High Alarm
123 RTD 4 High Alarm
124 RTD 5 High Alarm
125 RTD 6 High Alarm
126 RTD 7 High Alarm
127 RTD 8 High Alarm
128 RTD 9 High Alarm
129 RTD 10 High Alarm
Table 8: Data Formats (Sheet 11 of 15)
CODE TYPE DEFINITION
