134 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
DEVICENET PROTOCOL COMMUNICATIONS GUIDE
02h CURRENT
ANGLES
1,2 (low,high) Ia angle 16 bits N/A, 0, 359 degrees F1
3,4 (low,high) Ib angle 16 bits N/A, 0, 359 degrees F1
5,6 (low,high) Ic angle 16 bits N/A, 0, 359 degrees F1
03h DIFF
CURRENTS
1,2 (low,high) Phase A differential current 16 bits 0, 0, 5000 A F1
3,4 (low,high) Phase B differential current 16 bits 0, 0, 5000 A F1
5,6 (low,high) Phase C differential current 16 bits 0, 0, 5000 A F1
04h MOTOR LOAD
1,2 (low,high) Motor load 16 bits 0, 0, 2000 FLA F3
3,4 (low,high) Current unbalance 16 bits 0, 0, 100 % F1
5,6 (low,high) Equivalent motor load 16 bits 0, 0, 2000 FLA F3
05h LINE
VOLTAGES
1,2 (low,high) Vab 16 bits 0, 0, 20000 V F1
3,4 (low,high) Vbc 16 bits 0, 0, 20000 V F1
5,6 (low,high) Vca 16 bits 0, 0, 20000 V F1
7,8 (low,high) Average line voltage 16 bits 0, 0, 20000 V F1
06h VOLTAGE
ANGLES
1,2 (low,high) Va angle 16 bits 0, 0, 20000 degrees F1
3,4 (low,high) Vb angle 16 bits 0, 0, 20000 degrees F1
5,6 (low,high) Vc angle 16 bits 0, 0, 20000 degrees F1
07h POWER
1,2 (low,high) Power factor 16 bits 0, -99, 100 PF F21
3 to 6 (low,high) Real power 32 bits 0, -99999, 99999 kW F12
7,8 (low,high) Real power (HP) 16 bits 0, 0, 65535 hp F1
9 to 12 (low,high) Reactive power 32 bits 0, -99999, 99999 kvar F12
13,14 (low,high) Apparent power 16 bits 0, 0, 65535 kVA F1
08h ENERGY
1 to 4 (low,high) MWh consumption 32 bits 0, 0, 999999999 MWh F17
5 to 8 (low,high) Mvarh consumption 32 bits 0, 0, 999999999 Mvar F17
9 to 12 (low,high) Mvarh generation 32 bits 0, 0, 999999999 Mvar F17
09h DEMAND
1 to 4 (low,high) Current demand 32 bits 0, 0, 100000 A F9
5 to 8 (low,high) Real power demand 32 bits 0, -50000, 50000 kW F12
9 to 12 (low,high) Reactive power demand 32 bits 0, -50000, 50000 kvar F12
13,14 (low,high) Apparent power demand 16 bits 0, 0, 50000 kVA F1
0Ah PEAK
DEMAND
1 to 4 (low,high) Peak current demand 32 bits 0, 0, 100000 A F9
5 to 8 (low,high) Peak real power demand 32 bits 0, -50000, 50000 kW F12
9 to 12 (low,high) Peak reactive power demand 32 bits 0, -50000, 50000 kvar F12
13,14 (low,high) Peak apparent power demand 16 bits 0, 0, 50000 kVA F1
Table 28: Data formats for class B0h, Instance 01h:
Attribute Bytes Description Length Default, Min, Max Value/Unit
Format
Code
