GE 469

COMMUNICATIONS GUIDE DEVICENET PROTOCOL
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 135
0Bh SPEED &
TORQUE
1 to 4 (low,high) Torque 32 bits 0, 0, 9999999 N.m/ ft.lb F10
5,6 (low,high) Tachometer RPM 16 bits 0, 0, 7200 RPM F1
7,8 (low,high) Motor speed 16 bits 0, 0, 1 -- F135
0Ch ANALOG
INPUTS
1 to 4 (low,high) Analog input 1 32 bits 0, -50000, 50000 -- F12
5 to 8 (low,high) Analog input 2 32 bits 0, -50000, 50000 -- F12
9 to 12 (low,high) Analog input 3 32 bits 0, -50000, 50000 -- F12
13 to 16 (low,high) Analog input 4 32 bits 0, -50000, 50000 -- F12
17 to 20 (low,high) Analog difference 1-2 32 bits 0, -100000, 100000 -- F12
21 to 24 (low,high) Analog difference 3-4 32 bits 0, -100000, 100000 -- F12
0Dh MOTOR
STATISTICS
1,2 (low,high) Number of motor starts 16 bits 0, 0, 50000 -- F1
3,4 (low,high) Number of emergency restarts 16 bits 0, 0, 50000 -- F1
5,6 (low,high) Number of starter operations 16 bits 0, 0, 50000 -- F1
7 to 10 (low,high) Digital counter 32 bits 0, 0, 1000000000 -- F9
11 to 14 (low,high) Motor running hours 32 bits 0, 0, 500 hours F9
15,16 (low,high) Time between starts 16 bits 10, 0, 500 minutes F1
0Eh
TEMPERATURES
1,2 (low,high) RTD #1 temperature 16 bits 0, -50, 250
0
C
F4
3,4 (low,high) RTD #2 temperature 16 bits 0, -50, 250
0
C
F4
5,6 (low,high) RTD #3 temperature 16 bits 0, -50, 250
0
C
F4
7,8 (low,high) RTD #4 temperature 16 bits 0, -50, 250
0
C
F4
9,10 (low,high) RTD #5 temperature 16 bits 0, -50, 250
0
C
F4
11,12 (low,high) RTD #6 temperature 16 bits 0, -50, 250
0
C
F4
13,14 (low,high) RTD #7 temperature 16 bits 0, -50, 250
0
C
F4
15,16 (low,high) RTD #8 temperature 16 bits 0, -50, 250
0
C
F4
17,18 (low,high) RTD #9 temperature 16 bits 0, -50, 250
0
C
F4
19,20 (low,high) RTD #10 temperature 16 bits 0, -50, 250
0
C
F4
21,22 (low,high) RTD #11 temperature 16 bits 0, -50, 250
0
C
F4
23,24 (low,high) RTD #12 temperature 16 bits 0, -50, 250
0
C
F4
0Fh LAST TRIP
DATE & TIME
1 to 4 (low,high) Time of Last Trip 32 bits N/A, N/A, N/A -- F19
5 to 8 (low,high) Date of Last Trip 32 bits N/A, N/A, N/A -- F18
Table 28: Data formats for class B0h, Instance 01h:
Attribute Bytes Description Length Default, Min, Max Value/Unit
Format
Code
