GE 469

136 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
DEVICENET PROTOCOL COMMUNICATIONS GUIDE
10h ALARM DATA
1 Pressure switch 8bits 0, 0, 4 -- F160
2 Vibration switch 8bits 0, 0, 4 -- F160
3 Digital counter 8bits 0, 0, 4 -- F160
4 Tachometer 8bits 0, 0, 4 -- F160
5 General switch A 8bits 0, 0, 4 -- F160
6 General switch B 8bits 0, 0, 4 -- F160
7 General switch C 8bits 0, 0, 4 -- F160
8 General switch D 8bits 0, 0, 4 -- F160
9 Thermal capacity 8bits 0, 0, 4 -- F160
10 Overload 8bits 0, 0, 4 -- F160
11 Undercurrent 8bits 0, 0, 4 -- F160
12 Current unbalance 8bits 0, 0, 4 -- F160
13 Ground fault 8bits 0, 0, 4 -- F160
14 RTD 1 8bits 0, 0, 4 -- F160
15 RTD 2 8bits 0, 0, 4 -- F160
16 RTD 3 8bits 0, 0, 4 -- F160
17 RTD 4 8bits 0, 0, 4 -- F160
18 RTD 5 8bits 0, 0, 4 -- F160
19 RTD 6 8bits 0, 0, 4 -- F160
20 RTD 7 8bits 0, 0, 4 -- F160
21 RTD 8 8bits 0, 0, 4 -- F160
Table 28: Data formats for class B0h, Instance 01h:
Attribute Bytes Description Length Default, Min, Max Value/Unit
Format
Code
