GE 469

COMMUNICATIONS GUIDE DEVICENET PROTOCOL
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 137
10h ALARM DATA
ctd.
22 RTD 9 8bits 0, 0, 4 -- F160
23 RTD 10 8bits 0, 0, 4 -- F160
24 RTD 11 8bits 0, 0, 4 -- F160
25 RTD 12 8bits 0, 0, 4 -- F160
26 Open RTD sensor 8bits 0, 0, 4 -- F160
27 Short sensor / low temperature 8bits 0, 0, 4 -- F160
28 Undervoltage 8bits 0, 0, 4 -- F160
29 Overvoltage 8bits 0, 0, 4 -- F160
30 System frequency 8bits 0, 0, 4 -- F160
31 Power factor 8bits 0, 0, 4 -- F160
32 Reactive power 8bits 0, 0, 4 -- F160
33 Underpower 8bits 0, 0, 4 -- F160
34 Trip counter 8bits 0, 0, 4 -- F160
35 Starter failure 8bits 0, 0, 4 -- F160
36 Current demand 8bits 0, 0, 4 -- F160
37 kW demand 8bits 0, 0, 4 -- F160
38 kvar demand 8bits 0, 0, 4 -- F160
39 kVA demand 8bits 0, 0, 4 -- F160
40 Analog input 1 8bits 0, 0, 4 -- F160
41 Analog input 2 8bits 0, 0, 4 -- F160
42 Analog input 3 8bits 0, 0, 4 -- F160
43 Analog input 4 8bits 0, 0, 4 -- F160
44 Reverse power 8bits 0, 0, 4 -- F160
45 RTD 1 High 8bits 0, 0, 4 -- F160
46 RTD 2 high 8bits 0, 0, 4 -- F160
47 RTD 3 High 8bits 0, 0, 4 -- F160
48 RTD 4 high 8bits 0, 0, 4 -- F160
49 RTD 5 High 8bits 0, 0, 4 -- F160
50 RTD 6 high 8bits 0, 0, 4 -- F160
51 RTD 7 high 8bits 0, 0, 4 -- F160
52 RTD 8 high 8bits 0, 0, 4 -- F160
53 RTD 9 high 8bits 0, 0, 4 -- F160
54 RTD 10 high 8bits 0, 0, 4 -- F160
55 RTD 11 high 8bits 0, 0, 4 -- F160
56 RTD 12 high 8bits 0, 0, 4 -- F160
Table 28: Data formats for class B0h, Instance 01h:
Attribute Bytes Description Length Default, Min, Max Value/Unit
Format
Code
