GE 469

28 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
027E RTD #12 alarm status 0 4 1 -- F123 0
027F Open RTD sensor alarm status 0 4 1 -- F123 0
0280 Short sensor / low temperature alarm status 0 4 1 -- F123 0
0281 Undervoltage alarm status 0 4 1 -- F123 0
0282 Overvoltage alarm status 0 4 1 -- F123 0
0283 System frequency alarm status 0 4 1 -- F123 0
0284 Power factor alarm status 0 4 1 -- F123 0
0285 Reactive power alarm status 0 4 1 -- F123 0
0286 Underpower alarm status 0 4 1 -- F123 0
0287 Trip counter alarm status 0 4 1 -- F123 0
0288 Starter failure alarm 0 4 1 -- F123 0
0289 Current demand alarm status 0 4 1 -- F123 0
028A kW demand alarm status 0 4 1 -- F123 0
028B kvar demand alarm status 0 4 1 -- F123 0
028C kVA demand alarm status 0 4 1 -- F123 0
028D Analog input 1 alarm status 0 4 1 -- F123 0
028E Analog input 2 alarm status 0 4 1 -- F123 0
028F Analog input 3 alarm status 0 4 1 -- F123 0
0290 Analog input 4 alarm status 0 4 1 -- F123 0
0291 Reverse power alarm status 0 4 1 -- F123 0
0292 RTD #1 high alarm status 0 4 1 -- F123 0
0293 RTD #2 high alarm status 0 4 1 -- F123 0
0294 RTD #3 high alarm status 0 4 1 -- F123 0
0295 RTD #4 high alarm status 0 4 1 -- F123 0
0296 RTD #5 high alarm status 0 4 1 -- F123 0
0297 RTD #6 high alarm status 0 4 1 -- F123 0
0298 RTD #7 high alarm status 0 4 1 -- F123 0
0299 RTD #8 high alarm status 0 4 1 -- F123 0
029A RTD #9 high alarm status 0 4 1 -- F123 0
029B RTD #10 high alarm status 0 4 1 -- F123 0
029C RTD #11 high alarm status 0 4 1 -- F123 0
029D RTD #12 high alarm status 0 4 1 -- F123 0
029E Analog difference 1-2 alarm status 0 4 1 -- F123 0
029F Analog difference 3-4 alarm status 0 4 1 -- F123 0
02A0 Overtorque alarm status 0 4 1 -- F123 0
02A1 Reserved
02A2 Reserved
...
02AE Loss of Comms Alarm Status 0 4 1 -- F123 0
02AF Self test alarm 0 FFFF 1 -- -- 0
START
BLOCKS
02B0 Overload lockout block 0 500 1 minutes F1 0
02B1 Start inhibit block lockout time 0 500 1 minutes F1 0
Table 7: 469 MEMORY MAP (Sheet 10 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
