GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 29
02B2 Starts/hour block lockout time 0 60 1 minutes F1 0
02B3 Time between starts lockout time 0 500 1 minutes F1 0
02B4 Restart block lockout 0 50000 1 s F1 0
02B5 Reserved
-- --
02CF Reserved
DIGITAL
INPUTS
02D0 Access switch status 0 1 1 -- F131 0
02D1 Test switch status 0 1 1 -- F131 0
02D2 Starter switch status 0 1 1 -- F131 0
02D3 Emergency restart switch status 0 1 1 -- F131 0
02D4 Remote reset switch status 0 1 1 -- F131 0
02D5 Assignable switch #1 status 0 1 1 -- F131 0
02D6 Assignable switch #2 status 0 1 1 -- F131 0
02D7 Assignable switch #3 status 0 1 1 -- F131 0
02D8 Assignable switch #4 status 0 1 1 -- F131 0
02D9 Trip coil supervision 0 1 1 -- F132 0
02DA Reserved
-- --
02DF Reserved
LOSS OF
COMMS
02E0Loss of Comms Port 011--F1670
02E1 Reserved
-- --
02FB Reserved
REAL TIME
CLOCK
02FCDate (read only) ------------
02FETime (read only) ------------
CURRENT
METERING
0300 Phase A current 0 100000 1 A F9 0
0302 Phase B current 0 100000 1 A F9 0
0304 Phase C current 0 100000 1 A F9 0
0306 Average phase current 0 100000 1 A F9 0
0308 Motor load 0 2000 1 FLA F3 0
0309 Current unbalance 0 100 1 % F1 0
030A Equivalent motor load 0 2000 1 FLA F3 0
030B Ground current 0 5000 1 A F11 0
030D Phase A differential current 0 5000 1 A F1 0
030E Phase B differential current 0 5000 1 A F1 0
030F Phase C differential current 0 5000 1 A F1 0
0310 Reserved
0311 Reserved
-- --
031F Reserved
Table 7: 469 MEMORY MAP (Sheet 11 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
