GE 469

30 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
TEMPER-
ATURE
0320 Hottest stator RTD –50 250 1 °C F4 0
0321 RTD #1 temperature –50 250 1 °C F4 0
0322 RTD #2 temperature –50 250 1 °C F4 0
0323 RTD #3 temperature –50 250 1 °C F4 0
0324 RTD #4 temperature –50 250 1 °C F4 0
0325 RTD #5 temperature –50 250 1 °C F4 0
0326 RTD #6 temperature –50 250 1 °C F4 0
0327 RTD #7 temperature –50 250 1 °C F4 0
0328 RTD #8 temperature –50 250 1 °C F4 0
0329 RTD #9 temperature –50 250 1 °C F4 0
032A RTD #10 temperature –50 250 1 °C F4 0
032B RTD #11 temperature –50 250 1 °C F4 0
032C RTD #12 temperature –50 250 1 °C F4 0
032D Reserved
032E Reserved
032F Reserved
0330 Hottest stator RTD (in Fahrenheit) –58 482 1 °F F4 32
0331 RTD #1 temperature (in Fahrenheit) –58 482 1 °F F4 32
0332 RTD #2 temperature (in Fahrenheit) –58 482 1 °F F4 32
0333 RTD #3 temperature (in Fahrenheit) –58 482 1 °F F4 32
0334 RTD #4 temperature (in Fahrenheit) –58 482 1 °F F4 32
0335 RTD #5 temperature (in Fahrenheit) –58 482 1 °F F4 32
0336 RTD #6 temperature (in Fahrenheit) –58 482 1 °F F4 32
0337 RTD #7 temperature (in Fahrenheit) –58 482 1 °F F4 32
0338 RTD #8 temperature (in Fahrenheit) –58 482 1 °F F4 32
0339 RTD #9 temperature (in Fahrenheit) –58 482 1 °F F4 32
033A RTD #10 temperature (in Fahrenheit) –58 482 1 °F F4 32
033B RTD #11 temperature (in Fahrenheit) –58 482 1 °F F4 32
033C RTD #12 temperature (in Fahrenheit) –58 482 1 °F F4 32
033D Reserved
033E Reserved
033F Reserved
VOLTAGE
METERING
0340 Vab 0 20000 1 V F1 0
0341 Vbc 0 20000 1 V F1 0
0342 Vca 0 20000 1 V F1 0
0343 Average line voltage 0 20000 1 V F1 0
0344 Van 0 20000 1 V F1 0
0345 Vbn 0 20000 1 V F1 0
0346 Vcn 0 20000 1 V F1 0
0347 Average phase voltage 0 20000 1 V F1 0
0348 System frequency 0 12000 1 Hz F3 0
Table 7: 469 MEMORY MAP (Sheet 12 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
