GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 31
0349 Reserved
034A Reserved
... ...
035F Reserved
SPEED 0360 Tachometer RPM 0 7200 1 RPM F1 0
0361 Reserved
0362 Reserved
... ...
036F Reserved
POWER
METERING
0370 Power factor –99 100 1 - F21 0
0371 Real power –99999 99999 1 kW F12 0
0373 Real power (HP) 0 65535 1 hp F1 0
0374 Reactive power –99999 99999 1 kvar F12 0
0376 Apparent power 0 65535 1 kVA F1 0
0377 MWh consumption 0
99999999
9
1MWhF170
0379 Mvarh consumption 0
99999999
9
1MvarhF170
037B Mvarh generation 0
99999999
9
1MvarhF170
037D Torque 0 9999999 1 Nm/ftlb F10 0
037F Reserved
0380 Reserved
... ...
038F Reserved
DEMAND
METERING
0390 Current demand 0 100000 1 A F9 0
0392 Real power demand 0 99999 1 kW F12 0
0394 Reactive power demand 0 99999 1 kvar F12 0
0396 Apparent power demand 0 65535 1 kVA F1 0
0397 Peak current demand 0 100000 1 A F9 0
0399 Peak real power demand 0 99999 1 kW F12 0
039B Peak reactive power demand 0 99999 1 kvar F12 0
039D Peak apparent power demand 0 65535 1 kVA F1 0
039E Reserved
039F Reserved
... ...
03AF Reserved
ANALOG
INPUTS
03B0 Analog input 1 –50000 50000 1 -- F12 0
03B2 Analog input 2 –50000 50000 1 -- F12 0
03B4 Analog input 3 –50000 50000 1 -- F12 0
03B6 Analog input 4 –50000 50000 1 -- F12 0
03B8 Analog input 1-2 difference –100000 100000 1 -- F12 0
03BA Analog input 3-4 difference –100000 100000 1 -- F12 0
Table 7: 469 MEMORY MAP (Sheet 13 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
