32 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
03BC Reserved
03BD Reserved
03BE Reserved
03BF Reserved
MOTOR
STARTING
03C0 Learned acceleration time 0 2000 1 s F2 0
03C1 Learned starting current 0 50000 1 A F9 0
03C3 Learned starting capacity 0 100 1 % F1 0
03C4 Last acceleration time 0 2000 1 s F2 0
03C5 Last starting current 0 50000 1 A F9 0
03C7 Last starting capacity 0 100 1 % F1 0
03C8 Reserved
03C9 Reserved
... ...
03CF Reserved
AVERAGE
MOTOR LOAD
03D0 Average motor load learned 0 2000 1 × FLA F3 5
03D1 Reserved
03D2 Reserved
... ...
03DF Reserved
RTD
MAXIMUMS
03E0 RTD #1 maximum temperature (in °C) –50 250 1 °C F4 0
03E1 RTD #2 maximum temperature (in °C) –50 250 1 °C F4 0
03E2 RTD #3 maximum temperature (in °C) –50 250 1 °C F4 0
03E3 RTD #4 maximum temperature (in °C) –50 250 1 °C F4 0
03E4 RTD #5 maximum temperature (in °C) –50 250 1 °C F4 0
03E5 RTD #6 maximum temperature (in °C) –50 250 1 °C F4 0
03E6 RTD #7 maximum temperature (in °C) –50 250 1 °C F4 0
03E7 RTD #8 maximum temperature (in °C) –50 250 1 °C F4 0
03E8 RTD #9 maximum temperature (in °C) –50 250 1 °C F4 0
03E9 RTD #10 maximum temperature (in °C) –50 250 1 °C F4 0
03EA RTD #11 maximum temperature (in °C) –50 250 1 °C F4 0
03EB RTD #12 maximum temperature (in °C) –50 250 1 °C F4 0
03EC Reserved
03ED Reserved
03EE Reserved
03EF Reserved
03F0 RTD #1 maximum temperature (in °F) –58 482 1 °F F4 32
03F1 RTD #2 maximum temperature (in °F) –58 482 1 °F F4 32
03F2 RTD #3 maximum temperature (in °F) –58 482 1 °F F4 32
03F3 RTD #4 maximum temperature (in °F) –58 482 1 °F F4 32
03F4 RTD #5 maximum temperature (in °F) –58 482 1 °F F4 32
03F5 RTD #6 maximum temperature (in °F) –58 482 1 °F F4 32
Table 7: 469 MEMORY MAP (Sheet 14 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
