GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 33
03F6 RTD #7 maximum temperature (in °F) –58 482 1 °F F4 32
03F7 RTD #8 maximum temperature (in °F) –58 482 1 °F F4 32
03F8 RTD #9 maximum temperature (in °F) –58 482 1 °F F4 32
03F9 RTD #10 maximum temperature (in °F) –58 482 1 °F F4 32
03FA RTD #11 maximum temperature (in °F) –58 482 1 °F F4 32
03FB RTD #12 maximum temperature (in °F) –58 482 1 °F F4 32
03FC Reserved
03FD Reserved
03FE Reserved
03FF Reserved
ANALOG
INPUTS
MINIMUM /
MAXIMUM
0400 Analog input 1 minimum –50000 50000 1 -- F12 0
0402 Analog input 1 maximum –50000 50000 1 -- F12 0
0404 Analog input 2 minimum –50000 50000 1 -- F12 0
0406 Analog input 2 maximum –50000 50000 1 -- F12 0
0408 Analog input 3 minimum –50000 50000 1 -- F12 0
040A Analog input 3 maximum –50000 50000 1 -- F12 0
040C Analog input 4 minimum –50000 50000 1 -- F12 0
040E Analog input 4 maximum –50000 50000 1 -- F12 0
0410 Reserved
0411 Reserved
...
041F Reserved
CALIBRATION 0420 Original Calibration Date -- -- -- -- F18 --
0422 Last Calibration Date -- -- -- -- F18 --
0424 Reserved
0425 Reserved
... ...
042F Reserved
TRIP
COUNTERS
0430 Total number of trips 0 50000 1 -- F1 0
0431 Incomplete sequence trips 0 50000 1 -- F1 0
0432 Input switch trips 0 50000 1 -- F1 0
0433 Tachometer trips 0 50000 1 -- F1 0
0434 Overload trips 0 50000 1 -- F1 0
0435 Short circuit trips 0 50000 1 -- F1 0
0436 Mechanical jam trips 0 50000 1 -- F1 0
0437 Undercurrent trips 0 50000 1 -- F1 0
0438 Current unbalance trips 0 50000 1 -- F1 0
0439 Ground fault trips 0 50000 1 -- F1 0
043A Phase differential trips 0 50000 1 -- F1 0
043B Motor acceleration trips 0 50000 1 -- F1 0
Table 7: 469 MEMORY MAP (Sheet 15 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
