GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 35
469 MODEL
INFORMATION
04C0 Order code 0 65535 1 -- F136 --
04C1 Relay serial number (read only) -- -- 1 -- F22
A300000
0
04C5 Reserved
04C6 Reserved
... ...
04DF Reserved
CALIBRATION
INFO.
04E0 Original calibration date -- -- -- -- F18 --
04E2 Last calibration date -- -- -- -- F19 --
04E4 Reserved
04E5 Reserved
... ...
04FF Reserved
PHASORS 0500 Va angle 0 359 1 ° F1 --
0501 Vb angle 0 359 1 ° F1 --
0502 Vc angle 0 359 1 ° F1 --
0503 Ia angle 0 359 1 ° F1 --
0504 Ib angle 0 359 1 ° F1 --
0505 Ic angle 0 359 1 ° F1 --
0507 Reserved
0506 Reserved
... ...
0FFF Reserved
COMMUNICAT
IONS
0600 DeviceNet explicit connection status 0 5 1 - F151 0
0601 DeviceNet polled I/O connection status 0 5 1 - F151 0
0602 DeviceNet COS connection status 0 5 1 - F151 0
0603 DeviceNet port status 0 4 1 - F153 0
0604 DeviceNet link status 0 4 1 - F154 0
0605 DeviceNet serial number -- -- -- -- F22
“Unknow
n”
060ADeviceNet firmware version --------F22
“Unknow
n”
060B Reserved
060C Reserved
060D Reserved
060E Reserved
0610 CoBox serial number -- -- -- -- F22
“Unknow
n”
0624 CoBox MAC address -- -- -- -- F22
“Unknow
n”
0638 CoBox firmware version -- -- -- -- F22
“Unknow
n”
0639 Reserved
063A Reserved
Table 7: 469 MEMORY MAP (Sheet 17 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
