GE 469

36 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
... ...
064B Reserved
064C Ethernet status -- -- -- -- F152 --
064D Reserved
064E Reserved
... ...
0FFF Reserved
SETPOINTS (Addresses 1000 to 1FFF)
PREFERENCES 1000 Default message cycle time 5 100 5 s F2 20
1001 Default message timeout 10 900 1 s F1 300
1002 Reserved
1003 Average motor load calculation period 1 90 1 minutes F1 15
1004 Temperature display units 0 1 1 -- F100 0
1005 Trace memory trigger position 1 100 1 % F1 25
1006 Trace memory buffers 1 16 1 cycles F1 8
1007 Display update interval 1 60 1 s F2 4
1008 Cyclic load filter interval 0 32 1 cycles F1 0
1009 Passcode (write only) 0 99999999 1 -- F12 0
100B
Encrypted passcode (read only)
Note: From version 5.23 onward, relay
response to read request is 00000000.
-- -- -- -- F12 --
100C Reserved
100D Reserved
100E Reserved
100F Reserved
SERIAL PORTS 1010 Slave address 1 254 1 -- F1 254
1011 Computer RS485 baud rate 0 5 1 -- F101 4
1012 Computer RS485 parity 0 2 1 -- F102 0
1013 Auxiliary RS485 baud rate 0 5 1 -- F101 4
1014 Auxiliary RS485 parity 0 2 1 -- F102 0
1015 Front RS232 baud rate 0 5 1 -- F101 5
DEVICENET 1016 DeviceNet MAC ID 0 63 1 -- F1 32
1017DeviceNet baud rate 021--F1492
1018 Reserved
1019 Reserved
.... ...
101F Reserved
ETHERNET 1020 Ethernet IP address -- -- -- -- F150 0
1022 Ethernet subnet mask -- -- -- -- F150 FFFFFF00
1024 Ethernet gateway address -- -- -- -- F150 0
1025 Reserved
1026 Reserved
... ...
Table 7: 469 MEMORY MAP (Sheet 18 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
