GE 469

40 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
10F2 Scratchpad message 5 characters 37 and 38 32 127 1 -- F1 ‘ ’
10F3 Scratchpad message 5 characters 39 and 40 32 127 1 -- F1 ‘ ’
10F4 Reserved
10F4 Reserved
... ...
112F Reserved
CLEAR DATA 1130 Clear last trip data prompt 0 1 1 -- F103 0
1131 Reset MWh and Mvarh meters 0 1 1 -- F103 0
1132 Clear peak demand data 0 1 1 -- F103 0
1133 Clear RTD maximums 0 1 1 -- F103 0
1134 Clear analog input minimum/maximum data 0 1 1 -- F103 0
1135Clear trip counters 011--F1030
1136 Preset digital counter 0 1 1 -- F103 0
1137 Clear event records 0 1 1 -- F103 0
1138 Reserved
1139 Reserved
... ...
113F Reserved
INSTAL-
LATION
1140 Reset motor information 0 1 1 -- F103 0
1141 Reset starter information 0 1 1 -- F103 0
1142 Reserved
1143 Reserved
... ...
117F Reserved
CURRENT
SENSING
1180 Phase CT primary 1 5001 1 A F1 5001
1181 Motor full load amps 1 5001 1 A F1 5001
1182Ground CT type 031--F1043
1183 Ground CT primary 1 5000 1 A F1 100
1184 Phase differential CT type 0 2 1 -- F105 0
1185 Phase differential CT primary 1 5000 1 A F1 100
1186 Enable two speed motor option 0 1 1 -- F103 0
1187 Speed two phase CT primary 1 5000 1 A F1 100
1188 Speed two motor full load current 1 5000 1 A F1 1
1189 Reserved
1190 Reserved
... ...
119F Reserved
VOLTAGE
SENSING
11A0 Voltage transformer connection type 0 2 1 -- F106 0
11A1 Voltage transformer ratio 100 30000 1 -- F3 3500
11A2 Motor nameplate voltage 100 36000 1 V F1 4000
11A3 Enable single VT connection 0 1 1 -- F143 0
Table 7: 469 MEMORY MAP (Sheet 22 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
