GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 41
11A4 Reserved
11A5 Reserved
... ...
11BF Reserved
POWER
SYSTEM
11C0 Nominal system frequency 0 2 1 -- F107 0
11C1 System phase sequence 0 1 1 -- F124 0
11C2 Speed 2 phase sequence 0 1 1 -- F124 0
11C3 Reserved
11C3 Reserved
... ...
11C7 Reserved
SERIAL COM.
CONTROL
11C8 Serial communication control 0 1 1 -- F103 0
11C9 Assign start control relays 0 2 1 -- F137 0
11CA Reserved
11CB Reserved
... ...
11CF Reserved
REDUCED
VOLTAGE
11D0 Reduced voltage starting 0 1 1 -- F103 0
11D1 Control relays for reduced voltage starting 0 2 1 -- F137 2
11D2 Transition on 0 2 1 -- F108 0
11D3 Reduced voltage start level 25 300 1 %FLA F1 100
11D4 Reduced voltage start timer 1 600 1 s F1 200
11D5 Incomplete sequence trip relays 0 3 1 -- F111 0
11D6 Reserved
11D6 Reserved
... ...
122F Reserved
STARTER
STATUS
1230 Starter Status Switch 0 1 1 - F109 0
1231 Reserved
1232 Reserved
... ...
123F Reserved
ASSIGNABLE
INPUTS
1240 Assignable Input 1 Function 0 18 1 -- F110 0
1241 Assignable Input 2 Function 0 18 1 -- F110 0
1242 Assignable Input 3 Function 0 18 1 -- F110 0
1243 Assignable Input 4 Function 0 18 1 -- F110 0
1244 Reserved
1245 Reserved
... ...
1259 Reserved
Table 7: 469 MEMORY MAP (Sheet 23 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
