GE 469

42 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
REMOTE
ALARM
125A Remote alarm name characters 1 and 2 0 65535 1 -- F22 ‘Re’
125B Remote alarm name characters 3 and 4 0 65535 1 -- F22 ‘mo’
125C Remote alarm name characters 5 and 6 0 65535 1 -- F22 ‘te’
125D Remote alarm name characters 7 and 8 0 65535 1 -- F22 ‘ A’
125E Remote alarm name characters 9 and 10 0 65535 1 -- F22 ‘la’
125F Remote alarm name characters 11 and 12 0 65535 1 -- F22 ‘rm’
1260 Remote alarm name characters 13 and 14 0 65535 1 -- F22 ‘ ’
1261 Remote alarm name characters 15 and 16 0 65535 1 -- F22 ‘ ’
1262 Remote alarm name characters 17 and 18 0 65535 1 -- F22 ‘ ’
1263 Remote alarm name characters 19 and 20 0 65535 1 -- F22 ‘ ’
1264 Remote alarm function 1 2 1 -- F115 2
1265 Remote alarm relays 0 6 1 -- F113 0
1266 Remote alarm events 0 1 1 -- F103 0
1267 Reserved
1268 Reserved
... ...
1279 Reserved
REMOTE TRIP 127A Remote trip name characters 1 and 2 0 65535 1 -- F22 ‘Re’
127B Remote trip name characters 3 and 4 0 65535 1 -- F22 ‘mo’
127C Remote trip name characters 5 and 6 0 65535 1 -- F22 ‘te’
127D Remote trip name characters 7 and 8 0 65535 1 -- F22 ‘ T’
127E Remote trip name characters 9 and 10 0 65535 1 -- F22 ‘ri’
127F Remote trip name characters 11 and 12 0 65535 1 -- F22 ‘p ’
1280 Remote trip name characters 13 and 14 0 65535 1 -- F22 ‘ ’
1281 Remote trip name characters 15 and 16 0 65535 1 -- F22 ‘ ’
1282 Remote trip name characters 17 and 18 0 65535 1 -- F22 ‘ ’
1283 Remote trip name characters 19 and 20 0 65535 1 -- F22 ‘ ’
1284 Remote trip relays 0 3 1 -- F111 0
1285 Reserved
1286 Reserved
... ...
128F Reserved
SPEED
SWITCH TRIP
1290 Speed switch trip relays 0 3 1 -- F111 0
1291 Speed switch trip delay 10 2500 1 s F2 50
1292 Reserved
1293 Reserved
... ...
129F Reserved
LOAD SHED
TRIP
12A0 Load shed trip relays 0 3 1 -- F111 0
12A1 Reserved
12A2 Reserved
Table 7: 469 MEMORY MAP (Sheet 24 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
