GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 43
... ...
12AF Reserved
PRESSURE
SWITCH
ALARM
12B0 Block pressure switch alarm from start 0 5000 1 s F1 0
12B1Pressure switch alarm function 121--F1152
12B2 Pressure switch alarm relays 0 6 1 -- F113 0
12B3 Pressure switch alarm delay 1 1000 1 s F2 50
12B4 Pressure switch alarm events 0 1 1 -- F103 0
12B5 Reserved
12B6 Reserved
... ...
12BF Reserved
PRESSURE
SWITCH TRIP
12C0 Block pressure switch trip from start 0 5000 1 s F1 0
12C1 Pressure switch trip relays 0 3 1 -- F111 0
12C2 Pressure switch trip delay 1 1000 1 s F2 50
12C3 Reserved
12CD Reserved
12CE Reserved
12CF Reserved
VIBRATION
SWITCH
ALARM
12D0 Vibration switch alarm function 1 2 1 -- F115 2
12D1 Vibration switch alarm relays 0 6 1 -- F113 0
12D2 Vibration switch alarm delay 1 1000 1 s F2 50
12D3 Vibration switch alarm events 0 1 1 -- F103 0
12D4 Reserved
12D5 Reserved
... ...
12DF Reserved
VIBRATION
SWITCH TRIP
12E0 Vibration switch trip relays 0 3 1 -- F111 0
12E1 Vibration switch trip delay 1 1000 1 s F2 50
12E2 Reserved
12E3 Reserved
... ...
12F2 Reserved
DIGITAL
COUNTERS
12F3 1st and 2nd character of counter units name 0 65535 1 -- F22 ‘Un’
12F4 3rd and 4th character of counter units name 0 65535 1 -- F22 ‘it’
12F5 5th and 6th character of counter units name 0 65535 1 -- F22 ‘s ’
12F6 Digital counter preset value 0
10000000
00
1--F90
12F8Digital counter type 011--F1140
12F9 Digital counter alarm 0 2 1 -- F115 0
Table 7: 469 MEMORY MAP (Sheet 25 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
