GE 469

44 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
12FA Digital counter alarm relays 0 6 1 -- F113 0
12FB Digital counter alarm level 0
10000000
00
1--F9100
12FD Digital counter alarm pickup 0 1 1 -- F130 0
12FE Digital counter alarm events 0 1 1 -- F103 0
12FF Reserved
1300 Reserved
... ...
130F Reserved
TACHOMETER 1310 Rated speed 100 7200 1 RPM F1 3600
1311 Tachometer alarm 0 2 1 -- F115 0
1312 Tachometer alarm relays 0 6 1 -- F113 0
1313 Tachometer alarm speed 5 100 1 %Rated F1 10
1314 Tachometer alarm delay 1 250 1 s F1 1
1315 Tachometer alarm events 0 1 1 -- F103 0
1316 Tachometer trip 0 2 1 -- F115 0
1317 Tachometer trip relays 0 3 1 -- F111 0
1318 Tachometer trip speed 5 95 1 %Rated F1 10
1319 Tachometer trip delay 1 250 1 s F1 1
131A Reserved
131A Reserved
... ...
1335 Reserved
GENERAL
SWITCH A
1336 General switch A name, characters 1 and 2 0 65535 1 -- F22 ‘Ge’
1337 General switch A name, characters 3 and 4 0 65535 1 -- F22 ‘ne’
1338 General switch A name, characters 5 and 6 0 65535 1 -- F22 ‘ra’
1339 General switch A name, characters 7 and 8 0 65535 1 -- F22 ‘l ’
133A General switch A name, characters 9 and 10 0 65535 1 -- F22 ‘Sw’
133B General switch A name, characters 11 and 12 0 65535 1 -- F22 ‘ A’
133C General switch A normal state 0 1 1 -- F116 0
133D General switch A block input from start 0 5000 1 s F1 0
133E General switch A alarm 0 2 1 -- F115 0
133F General switch A alarm relays 0 6 1 -- F113 0
1340 General switch A alarm delay 1 50000 1 s F2 50
1341 General switch A alarm events 0 1 1 -- F103 0
1342 General switch A trip 0 2 1 -- F115 0
1343 General switch A trip relays 0 3 1 -- F111 0
1344 General switch A trip delay 1 50000 1 s F2 50
1345 Reserved
1346 Reserved
... ...
1365 Reserved
Table 7: 469 MEMORY MAP (Sheet 26 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
