GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 45
GENERAL
SWITCH B
1366 General switch B name, characters 1 and 2 0 65535 1 -- F22 ‘Ge’
1367 General switch B name, characters 3 and 4 0 65535 1 -- F22 ‘ne’
1368 General switch B name, characters 5 and 6 0 65535 1 -- F22 ‘ra’
1369 General switch B name, characters 7 and 8 0 65535 1 -- F22 ‘l ’
136A General switch B name, characters 9 and 10 0 65535 1 -- F22 ‘Sw’
136B General switch B name, characters 11 and 12 0 65535 1 -- F22 ‘ B’
136C General switch B normal state 0 1 1 -- F116 0
136D General switch B block input from start 0 5000 1 s F1 0
136E General switch B alarm 0 2 1 -- F115 0
136F General switch B alarm relays 0 6 1 -- F113 0
1370 General switch B alarm delay 1 50000 1 s F2 50
1371 General switch B alarm events 0 1 1 -- F103 0
1372 General switch B trip 0 2 1 -- F115 0
1373 General switch B trip relays 0 3 1 -- F111 0
1374 General switch B trip delay 1 50000 1 s F2 50
1375 Reserved
1376 Reserved
... ...
1395 Reserved
GENERAL
SWITCH C
1396 General switch C name, characters 1 and 2 0 65535 1 -- F22 ‘Ge’
1397 General switch C name, characters 3 and 4 0 65535 1 -- F22 ‘ne’
1398 General switch C name, characters 5 and 6 0 65535 1 -- F22 ‘ra’
1399 General switch C name, characters 7 and 8 0 65535 1 -- F22 ‘l ’
139A General switch C name, characters 9 and 10 0 65535 1 -- F22 ‘Sw’
139B General switch C name, characters 11 & 12 0 65535 1 -- F22 ‘ C’
139C General switch C normal state 0 1 1 -- F116 0
139D General switch C block input from start 0 5000 1 s F1 0
139E General switch C alarm 0 2 1 -- F115 0
139F General switch C alarm relays 0 6 1 -- F113 0
13A0 General switch C alarm delay 1 50000 1 s F2 50
13A1 General switch C alarm events 0 1 1 -- F103 0
13A2 General switch C trip 0 2 1 -- F115 0
13A3 General switch C trip relays 0 3 1 -- F111 0
13A4 General switch C trip delay 1 50000 1 s F2 50
13A5 Reserved
13A6 Reserved
... ...
13C5 Reserved
GENERAL
SWITCH D
13C6 General switch D name, characters 1 and 2 0 65535 1 -- F22 ‘Ge’
13C7 General switch D name, characters 3 and 4 0 65535 1 -- F22 ‘ne’
13C8 General switch D name, characters 5 and 6 0 65535 1 -- F22 ‘ra’
Table 7: 469 MEMORY MAP (Sheet 27 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
