GE 469

46 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
13C9 General switch D name, characters 7 and 8 0 65535 1 -- F22 ‘l ’
13CA General switch D name, characters 9 and 10 0 65535 1 -- F22 ‘Sw’
13CB General switch D name, characters 11 & 12 0 65535 1 -- F22 ‘ D’
13CC General switch D normal state 0 1 1 -- F116 0
13CD General switch D block input from start 0 5000 1 s F1 0
13CE General switch D alarm 0 2 1 -- F115 0
13CF General switch D alarm relays 0 6 1 -- F113 0
13D0 General switch D alarm delay 1 50000 1 s F2 50
13D1 General switch D alarm events 0 1 1 -- F103 0
13D2 General switch D trip 0 2 1 -- F115 0
13D3 General switch D trip relays 0 3 1 -- F111 0
13D4 General switch D trip delay 1 50000 1 s F2 50
13D5 Reserved
13D6 Reserved
... ...
14FF Reserved
RELAY RESET
MODE
1500 Reset mode 1 TRIP 0 2 1 -- F117 0
1501 Reset mode 2 AUXILIARY 0 2 1 -- F117 0
1502 Reset mode 3 AUXILIARY 0 2 1 -- F117 0
1503 Reset mode 4 ALARM 0 2 1 -- F117 0
1504 Reserved
1505 Reset mode 6 SERVICE 0 2 1 -- F117 0
FORCE
OUTPUT
RELAY
1506 Force 1 TRIP relay 0 1 1 -- F126 0
1507 Force 1 TRIP relay duration 0 300 1 s F1 0
1508 Force 2 AUXILIARY relay 0 1 1 -- F126 0
1509 Force 2 AUXILIARY relay duration 0 300 1 s F1 0
150A Force 3 AUXILIARY relay 0 1 1 -- F126 0
150B Force 3 AUXILIARY duration 0 300 1 s F1 0
150C Force 4 ALARM relay 0 1 1 -- F126 0
150D Force 4 ALARM relay duration 0 300 1 s F1 0
150EForce 5BLOCKSTART relay 011--F1260
150F Force 5 BLOCK START relay duration 0 300 1 s F1 0
1510 Reserved
1511 Reserved
... ...
157F Reserved
THERMAL
MODEL
1580Curve style 021--F1280
1581 Overload pickup level 101 125 1 × FLA F3 101
1582 Unbalance k factor 0 12 1 -- F1 0
1583 Cool time constant running 1 1000 1 minutes F1 15
Table 7: 469 MEMORY MAP (Sheet 28 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
