GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 47
1584 Cool time constant stopped 1 1000 1 minutes F1 30
1585 Hot/cold safe stall ratio 1 100 1 -- F3 100
1586 RTD biasing 0 1 1 -- F103 0
1587 RTD bias minimum 0 250 1 °C F1 40
1588 RTD bias center point 0 250 1 °C F1 130
1589 RTD bias maximum 0 250 1 °C F1 155
158A Thermal capacity alarm 0 2 1 -- F115 0
158B Thermal capacity alarm relays 0 6 1 -- F113 0
158C Thermal capacity alarm level 10 100 1 %used F1 75
158D Thermal capacity alarm events 0 1 1 -- F103 0
158E Overload trip relays 0 3 1 -- F111 0
158F Reserved
1590 Reserved
... ...
15AE Reserved
OVERLOAD
CURVE SETUP
15AF Standard overload curve number 1 15 1 -- F1 4
15B0 Time to trip at 1.01 x FLA 5 999999 1 s F10 174145
15B2 Time to trip at 1.05 x FLA 5 999999 1 s F10 34149
15B4 Time to trip at 1.10 x FLA 5 999999 1 s F10 16667
15B6 Time to trip at 1.20 x FLA 5 999999 1 s F10 7954
15B8 Time to trip at 1.30 x FLA 5 999999 1 s F10 5072
15BA Time to trip at 1.40 x FLA 5 999999 1 s F10 3646
15BC Time to trip at 1.50 x FLA 5 999999 1 s F10 2800
15BE Time to trip at 1.75 x FLA 5 999999 1 s F10 1697
15C0 Time to trip at 2.00 x FLA 5 999999 1 s F10 1166
15C2 Time to trip at 2.25 x FLA 5 999999 1 s F10 861
15C4 Time to trip at 2.50 x FLA 5 999999 1 s F10 666
15C6 Time to trip at 2.75 x FLA 5 999999 1 s F10 533
15C8 Time to trip at 3.00 x FLA 5 999999 1 s F10 437
15CA Time to trip at 3.25 x FLA 5 999999 1 s F10 366
15CC Time to trip at 3.50 x FLA 5 999999 1 s F10 311
15CE Time to trip at 3.75 x FLA 5 999999 1 s F10 268
15D0 Time to trip at 4.00 x FLA 5 999999 1 s F10 233
15D2 Time to trip at 4.25 x FLA 5 999999 1 s F10 205
15D4 Time to trip at 4.50 x FLA 5 999999 1 s F10 182
15D6 Time to trip at 4.75 x FLA 5 999999 1 s F10 162
15D8 Time to trip at 5.00 x FLA 5 999999 1 s F10 146
15DA Time to trip at 5.50 x FLA 5 999999 1 s F10 120
15DC Time to trip at 6.00 x FLA 5 999999 1 s F10 100
15DE Time to trip at 6.50 x FLA 5 999999 1 s F10 85
15E0 Time to trip at 7.00 x FLA 5 999999 1 s F10 73
15E2 Time to trip at 7.50 x FLA 5 999999 1 s F10 63
Table 7: 469 MEMORY MAP (Sheet 29 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
