GE 469

48 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
15E4 Time to trip at 8.00 x FLA 5 999999 1 s F10 56
15E6 Time to trip at 10.0 x FLA 5 999999 1 s F10 56
15E8 Time to trip at 15.0 x FLA 5 999999 1 s F10 56
15EA Time to trip at 20.0 x FLA 5 999999 1 s F10 56
15EC Reserved
15ED Reserved
... ...
15FF Reserved
1600 Minimum allowable line voltage 70 95 1 %Rated F1 80
1601 Stall current at minimum Vline 200 1500 1 × FLA F3 480
1602 Safe stall time at minimum Vline 5 9999 1 s F2 200
1603 Acceleration intersect at minimum Vline 200 1500 1 × FLA F3 380
1604 Stall current at 100% Vline 200 1500 1 × FLA F3 600
1605 Safe stall time at 100% Vline 5 9999 1 s F2 100
1606 Acceleration intersect at 100% Vline 200 1500 1 × FLA F3 500
1607 Reserved
1608 Reserved
……
163F Reserved
SHORT
CIRCUIT TRIP
1640 Short circuit trip 0 2 1 -- F115 0
1641 Overreach filter 0 1 1 -- F103 0
1642 Short circuit trip relays 0 6 1 -- F118 0
1643 Short circuit trip pickup 20 200 1 × CT F2 100
1644 Intentional short circuit trip delay 0 1000 10 ms F1 0
1645 Short circuit trip backup 0 1 1 -- F103 0
1646 Short circuit backup relays 0 2 1 -- F119 0
1647 Short circuit trip backup delay 10 2000 10 ms F1 200
1648 Reserved
1649 Reserved
--- ---
164F Reserved
OVERLOAD
ALARM
1650 Overload alarm 0 2 1 -- F115 0
1651 Overload alarm relays 0 6 1 -- F113 0
1652 Overload alarm events 0 1 1 -- F103 0
1653 Overload alarm delay 1 600 1 s F2 0
1654 Reserved
1655 Reserved
... ...
165F Reserved
MECHANICAL
JAM
1660 Mechanical jam trip 0 2 1 -- F115 0
1661 Mechanical jam trip relays 0 3 1 -- F111 0
Table 7: 469 MEMORY MAP (Sheet 30 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
