GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 49
1662 Mechanical jam pickup 101 300 1 × FLA F3 150
1663 Mechanical jam delay 1 30 1 s F1 1
1664 Reserved
1665 Reserved
... ...
166F Reserved
UNDER-
CURRENT
1670 Block undercurrent from start 0 15000 1 s F1 0
1671 Undercurrent alarm 0 2 1 -- F115 0
1672 Undercurrent alarm relays 0 6 1 -- F113 0
1673 Undercurrent alarm pickup 10 95 1 × FLA F3 70
1674 Undercurrent alarm delay 1 60 1 s F1 1
1675 Undercurrent alarm events 0 1 1 -- F103 0
1676 Undercurrent trip 0 2 1 -- F115 0
1677 Undercurrent trip relays 0 3 1 -- F111 0
1678 Undercurrent trip pickup 10 99 1 × FLA F3 70
1679 Undercurrent trip delay 1 60 1 s F1 1
167A Reserved
167B Reserved
167C Reserved
167D Reserved
167E Reserved
167F Reserved
CURRENT
UNBALANCE
1680 Current unbalance alarm 0 2 1 -- F115 0
1681 Current unbalance alarm relays 0 6 1 -- F113 0
1682 Current unbalance alarm pickup 4 40 1 % F1 15
1683 Current unbalance alarm delay 1 60 1 s F1 1
1684 Current unbalance alarm events 0 1 1 -- F103 0
1685 Current unbalance trip 0 2 1 -- F115 0
1686 Current unbalance trip relays 0 3 1 -- F111 0
1687 Current unbalance trip pickup 4 40 1 % F1 20
1688 Current unbalance trip delay 1 60 1 s F1 1
1689 Reserved
1690 Reserved
... ...
169F Reserved
GROUND
FAULT
16A0 Reserved
16A1 Ground fault alarm 0 2 1 -- F115 0
16A2 Ground fault alarm relays 0 6 1 -- F113 0
16A3 Ground fault alarm pickup 10 100 1 × CT F3 10
16A4 Alarm pickup for 50/0.025 CT 25 2500 1 A F3 100
16A5 Intentional ground fault alarm delay 0 1000 10 ms F1 0
Table 7: 469 MEMORY MAP (Sheet 31 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
