GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 51
16F4 Reserved
... ...
16FF Reserved
RESTART
BLOCK
1700 Restart block 0 1 1 -- F103 0
1701 Restart block time 1 50000 1 s F1 1
1702 Reserved
1703 Reserved
... ...
177F Reserved
RTD TYPES 1780 Stator RTD type 0 3 1 -- F120 0
1781 Bearing RTD type 0 3 1 -- F120 0
1782 Ambient RTD type 0 3 1 -- F120 0
1783 Other RTD type 0 3 1 -- F120 0
1784 Reserved
1785 Reserved
... ...
178F Reserved
RTD #1 1790 RTD #1 application 0 4 1 -- F121 1
1791 RTD #1 alarm 0 2 1 -- F115 0
1792 RTD #1 alarm relays 0 6 1 -- F113 0
1793 RTD #1 alarm temperature 1 250 1 °C F1 130
1794 RTD #1 alarm events 0 1 1 -- F103 0
1795RTD #1 trip 021--F1150
1796 RTD #1 trip voting 1 12 1 -- F122 1
1797 RTD #1 trip relays 0 3 1 -- F111 0
1798 RTD #1 trip temperature 1 250 1 °C F1 155
1799 1st and 2nd characters of RTD #1 name 0 65535 1 -- F22 ‘ ’
1799 3rd and 4th characters of RTD #1 name 0 65535 1 -- F22 ‘ ’
1799 5th and 6th characters of RTD #1 name 0 65535 1 -- F22 ‘ ’
179C 7th and 8th characters of RTD #1 name 0 65535 1 -- F22 ‘ ’
179D Reserved
179E Reserved
... ...
17AD Reserved
17AE RTD #1 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
17AF RTD #1 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #2 17B0 RTD #2 application 0 4 1 -- F121 1
17B1RTD #2 alarm 021--F1150
17B2RTD #2 alarm relays 061--F1130
17B3 RTD #2 alarm temperature 1 250 1 °C F1 130
17B4 RTD #2 alarm events 0 1 1 -- F103 0
17B5RTD #2 trip 021--F1150
Table 7: 469 MEMORY MAP (Sheet 33 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
