52 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
17B6 RTD #2 trip voting 1 12 1 -- F122 2
17B7 RTD #2 trip relays 0 3 1 -- F111 0
17B8 RTD #2 trip temperature 1 250 1 °C F1 155
17B9 1st and 2nd characters of RTD #2 name 0 65535 1 -- F22 ‘ ’
17BA 3rd and 4th characters of RTD #2 name 0 65535 1 -- F22 ‘ ’
17BB 5th and 6th characters of RTD #2 name 0 65535 1 -- F22 ‘ ’
17BC 7th and 8th characters of RTD #2 name 0 65535 1 -- F22 ‘ ’
17BD Reserved
17BE Reserved
... ...
17CD Reserved
17CE RTD #2 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
17CF RTD #2 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #3 17D0 RTD #3 application 0 4 1 -- F121 1
17D1 RTD #3 alarm 0 2 1 -- F115 0
17D2 RTD #3 alarm relays 0 6 1 -- F113 0
17D3 RTD #3 alarm temperature 1 250 1 °C F1 130
17D4 RTD #3 alarm events 0 1 1 -- F103 0
17D5 RTD #3 trip 0 2 1 -- F115 0
17D6 RTD #3 trip voting 1 12 1 -- F122 3
17D7 RTD #3 trip relays 0 3 1 -- F111 0
17D8 RTD #3 trip temperature 1 250 1 °C F1 155
17D9 1st and 2nd characters of RTD #3 name 0 65535 1 -- F22 ‘ ’
17DA 3rd and 4th characters of RTD #3 name 0 65535 1 -- F22 ‘ ’
17DB 5th and 6th characters of RTD #3 name 0 65535 1 -- F22 ‘ ’
17DC 7th and 8th characters of RTD #3 name 0 65535 1 -- F22 ‘ ’
17DD Reserved
17DE Reserved
... ...
17ED Reserved
17EE RTD #3 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
17EF RTD #3 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #4 17F0 RTD #4 application 0 4 1 -- F121 1
17F1RTD #4 alarm 021--F1150
17F2RTD #4 alarm relays 061--F1130
17F3 RTD #4 alarm temperature 1 250 1 °C F1 130
17F4 RTD #4 alarm events 0 1 1 -- F103 0
17F5RTD #4 trip 021--F1150
17F6 RTD #4 trip voting 1 12 1 -- F122 4
17F7 RTD #4 trip relays 0 3 1 -- F111 0
17F8 RTD #4 trip temperature 1 250 1 °C F1 155
17F9 1st and 2nd characters of RTD #4 name 0 65535 1 -- F22 ‘ ’
Table 7: 469 MEMORY MAP (Sheet 34 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
