GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 53
17FA 3rd and 4th characters of RTD #4 name 0 65535 1 -- F22 ‘ ’
17FB 5th and 6th characters of RTD #4 name 0 65535 1 -- F22 ‘ ’
17FC 7th and 8th characters of RTD #4 name 0 65535 1 -- F22 ‘ ’
17FD Reserved
17FE Reserved
... ...
180D Reserved
180E RTD #4 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
180F RTD #4 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #5 1810 RTD #5 application 0 4 1 -- F121 1
1811 RTD #5 alarm 0 2 1 -- F115 0
1812 RTD #5 alarm relays 0 6 1 -- F113 0
1813 RTD #5 alarm temperature 1 250 1 °C F1 130
1814 RTD #5 alarm events 0 1 1 -- F103 0
1815RTD #5 trip 021--F1150
1816 RTD #5 trip voting 1 12 1 -- F122 5
1817 RTD #5 trip relays 0 3 1 -- F111 0
1818 RTD #5 trip temperature 1 250 1 °C F1 155
1819 1st and 2nd characters of RTD #5 name 0 65535 1 -- F22 ‘ ’
181A 3rd and 4th characters of RTD #5 name 0 65535 1 -- F22 ‘ ’
181B 5th and 6th characters of RTD #5 name 0 65535 1 -- F22 ‘ ’
181C 7th and 8th characters of RTD #5 name 0 65535 1 -- F22 ‘ ’
181D Reserved
181E Reserved
... ...
182D Reserved
182E RTD #5 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
182F RTD #5 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #6 1830 RTD #6 application 0 4 1 -- F121 1
1831 RTD #6 alarm 0 2 1 -- F115 0
1832 RTD #6 alarm relays 0 6 1 -- F113 0
1833 RTD #6 alarm temperature 1 250 1 °C F1 130
1834 RTD #6 alarm events 0 1 1 -- F103 0
1835RTD #6 trip 021--F1150
1836 RTD #6 trip voting 1 12 1 -- F122 6
1837 RTD #6 trip relays 0 3 1 -- F111 0
1838 RTD #6 trip temperature 1 250 1 °C F1 155
1839 1st and 2nd characters of RTD #6 name 0 65535 1 -- F22 ‘ ’
183A 3rd and 4th characters of RTD #6 name 0 65535 1 -- F22 ‘ ’
183B 5th and 6th characters of RTD #6 name 0 65535 1 -- F22 ‘ ’
183C 7th and 8th characters of RTD #6 name 0 65535 1 -- F22 ‘ ’
183D Reserved
Table 7: 469 MEMORY MAP (Sheet 35 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
