GE 469

54 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
183E Reserved
... ...
184D Reserved
184E RTD #6 alarm temperature (in Fahrenheit) 34 482 1 °F F1 266
184F RTD #6 trip temperature (in Fahrenheit) 34 482 1 °F F1 311
RTD #7 1850 RTD #7 application 0 4 1 -- F121 2
1851 RTD #7 alarm 0 2 1 -- F115 0
1852 RTD #7 alarm relays 0 6 1 -- F113 0
1853 RTD #7 alarm temperature 1 250 1 °C F1 80
1854 RTD #7 alarm events 0 1 1 -- F103 0
1855RTD #7 trip 021--F1150
1856 RTD #7 trip voting 1 12 1 -- F122 7
1857 RTD #7 trip relays 0 3 1 -- F111 0
1858 RTD #7 trip temperature 1 250 1 °C F1 90
1859 1st and 2nd characters of RTD #7 name 0 65535 1 -- F22 ‘ ’
185A 3rd and 4th characters of RTD #7 name 0 65535 1 -- F22 ‘ ’
185B 5th and 6th characters of RTD #7 name 0 65535 1 -- F22 ‘ ’
185C 7th and 8th characters of RTD #7 name 0 65535 1 -- F22 ‘ ’
185D Reserved
185E Reserved
... ...
186D Reserved
186E RTD #7 alarm temperature (in Fahrenheit) 34 482 1 °F F1 176
186F RTD #7 trip temperature (in Fahrenheit) 34 482 1 °F F1 194
RTD #8 1870 RTD #8 application 0 4 1 -- F121 2
1871 RTD #8 alarm 0 2 1 -- F115 0
1872 RTD #8 alarm relays 0 6 1 -- F113 0
1873 RTD #8 alarm temperature 1 250 1 °C F1 80
1874 RTD #8 alarm events 0 1 1 -- F103 0
1875RTD #8 trip 021--F1150
1876 RTD #8 trip voting 1 12 1 -- F122 8
1877 RTD #8 trip relays 0 3 1 -- F111 0
1878 RTD #8 trip temperature 1 250 1 °C F1 90
1879 1st and 2nd characters of RTD #8 name 0 65535 1 -- F22 ‘ ’
187A 3rd and 4th characters of RTD #8 name 0 65535 1 -- F22 ‘ ’
187B 5th and 6th characters of RTD #8 name 0 65535 1 -- F22 ‘ ’
187C 7th and 8th characters of RTD #8 name 0 65535 1 -- F22 ‘ ’
187D Reserved
187E Reserved
... ...
188D Reserved
188E RTD #8 alarm temperature (in Fahrenheit) 34 482 1 °F F1 176
Table 7: 469 MEMORY MAP (Sheet 36 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
