GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 55
188F RTD #8 trip temperature (in Fahrenheit) 34 482 1 °F F1 194
RTD #9 1890 RTD #9 application 0 4 1 -- F121 2
1891 RTD #9 alarm 0 2 1 -- F115 0
1892 RTD #9 alarm relays 0 6 1 -- F113 0
1893 RTD #9 alarm temperature 1 250 1 °C F1 80
1894 RTD #9 alarm events 0 1 1 -- F103 0
1895RTD #9 trip 021--F1150
1896 RTD #9 trip voting 1 12 1 -- F122 9
1897 RTD #9 trip relays 0 3 1 -- F111 0
1898 RTD #9 trip temperature 1 250 1 °C F1 90
1899 1st and 2nd characters of RTD #9 name 0 65535 1 -- F22 ‘ ’
189A 3rd and 4th characters of RTD #9 name 0 65535 1 -- F22 ‘ ’
189B 5th and 6th characters of RTD #9 name 0 65535 1 -- F22 ‘ ’
189C 7th and 8th characters of RTD #9 name 0 65535 1 -- F22 ‘ ’
189D Reserved
189E Reserved
... ...
18AD Reserved
18AE RTD #9 alarm temperature (in Fahrenheit) 34 482 1 °F F1 176
18AF RTD #9 trip temperature (in Fahrenheit) 34 482 1 °F F1 194
RTD #10 18B0 RTD #10 application 0 4 1 -- F121 2
18B1 RTD #10 alarm 0 2 1 -- F115 0
18B2 RTD #10 alarm relays 0 6 1 -- F113 0
18B3 RTD #10 alarm temperature 1 250 1 °C F1 80
18B4 RTD #10 alarm events 0 1 1 -- F103 0
18B5 RTD #10 trip 0 2 1 -- F115 0
18B6 RTD #10 trip voting 1 12 1 -- F122 10
18B7 RTD #10 trip relays 0 3 1 -- F111 0
18B8 RTD #10 trip temperature 1 250 1 °C F1 90
18B9 1st and 2nd characters of RTD #10 name 0 65535 1 -- F22 ‘ ’
18BA 3rd and 4th characters of RTD #10 name 0 65535 1 -- F22 ‘ ’
18BB 5th and 6th characters of RTD #10 name 0 65535 1 -- F22 ‘ ’
18BC 7th and 8th characters of RTD #10 name 0 65535 1 -- F22 ‘ ’
18BD Reserved
18BE Reserved
... ...
18CD Reserved
18CE RTD #10 alarm temperature (in Fahrenheit) 34 482 1 °F F1 176
18CF RTD #10 trip temperature (in Fahrenheit) 34 482 1 °F F1 194
RTD #11 18D0 RTD #11 application 0 4 1 -- F121 4
18D1 RTD #11 alarm 0 2 1 -- F115 0
18D2 RTD #11 alarm relays 0 6 1 -- F113 0
Table 7: 469 MEMORY MAP (Sheet 37 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
