GE 469

56 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
18D3 RTD #11 alarm temperature 1 250 1 °C F1 80
18D4 RTD #11 alarm events 0 1 1 -- F103 0
18D5 RTD #11 trip 0 2 1 -- F115 0
18D6 RTD #11 trip voting 1 12 1 -- F122 11
18D7 RTD #11 trip relays 0 3 1 -- F111 0
18D8 RTD #11 trip temperature 1 250 1 °C F1 90
18D9 1st and 2nd characters of RTD #11 name 0 65535 1 -- F22 ‘ ’
18DA 3rd and 4th characters of RTD #11 name 0 65535 1 -- F22 ‘ ’
18DB 5th and 6th characters of RTD #11 name 0 65535 1 -- F22 ‘ ’
18DC 7th and 8th characters of RTD #11 name 0 65535 1 -- F22 ‘ ’
18DD Reserved
18DE Reserved
... ...
18ED Reserved
18EE RTD #11 alarm temperature (in Fahrenheit) 34 482 1 °F F1 176
18EF RTD #11 trip temperature (in Fahrenheit) 34 482 1 °F F1 194
RTD #12 18F0 RTD #12 application 0 4 1 -- F121 3
18F1 RTD #12 alarm 0 2 1 -- F115 0
18F2 RTD #12 alarm relays 0 6 1 -- F113 0
18F3 RTD #12 alarm temperature 1 250 1 °C F1 60
18F4 RTD #12 alarm events 0 1 1 -- F103 0
18F5 RTD #12 trip 0 2 1 -- F115 0
18F6 RTD #12 trip voting 1 12 1 -- F122 12
18F7 RTD #12 trip relays 0 3 1 -- F111 0
18F8 RTD #12 trip temperature 1 250 1 °C F1 80
18F9 1st and 2nd characters of RTD #12 name 0 65535 1 -- F22 ‘ ’
18FA 3rd and 4th characters of RTD #12 name 0 65535 1 -- F22 ‘ ’
18FB 5th and 6th characters of RTD #12 name 0 65535 1 -- F22 ‘ ’
18FC 7th and 8th characters of RTD #12 name 0 65535 1 -- F22 ‘ ’
18FD Reserved
18FE Reserved
... ...
190D Reserved
190E RTD #12 alarm temperature (in Fahrenheit) 34 482 1 °F F1 140
190F RTD #12 trip temperature (in Fahrenheit) 34 482 1 °F F1 176
OPEN RTD
SENSOR
1910 Open RTD Sensor Alarm 0 2 1 -- F115 0
1911 Open RTD Sensor Alarm Relays 0 6 1 -- F113 0
1912 Open RTD Sensor Alarm Events 0 1 1 -- F103 0
1913 Reserved
1914 Reserved
... ...
191F Reserved
Table 7: 469 MEMORY MAP (Sheet 38 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
