GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 57
RTD SHORT/
LOW TEMP
1920 RTD Short / Low Temp Alarm 0 2 1 -- F115 0
1921 RTD Short / Low Temp Alarm Relays 0 6 1 -- F113 0
1922 RTD Short / Low Temp Alarm Events 0 1 1 -- F103 0
1923 Reserved
1924 Reserved
... ...
192F Reserved
RTD HIGH
ALARMS
1930 RTD #1 high alarm 0 2 1 - F115 0
1931 RTD #1 high alarm relays 0 6 1 -- F113 0
1932 RTD #1 high alarm level 1 250 1 °C F1 130
1933 Reserved
1934 RTD #2 high alarm 0 2 1 -- F115 0
1935 RTD #2 high alarm relays 0 6 1 -- F113 0
1936 RTD #2 high alarm level 1 250 1 °C F1 130
1937 Reserved
1938 RTD #3 high alarm 0 2 1 -- F115 0
1939 RTD #3 high alarm relays 0 6 1 -- F113 0
193A RTD #3 high alarm level 1 250 1 °C F1 130
193B Reserved
193C RTD #4 high alarm 0 2 1 -- F115 0
193D RTD #4 high alarm relays 0 6 1 -- F113 0
193E RTD #4 high alarm level 1 250 1 °C F1 130
193F Reserved
1940 RTD #5 high alarm 0 2 1 -- F115 0
1941 RTD #5 high alarm relays 0 6 1 -- F113 0
1942 RTD #5 high alarm level 1 250 1 °C F1 130
1943 Reserved
1944 RTD #6 high alarm 0 2 1 -- F115 0
1945 RTD #6 high alarm relays 0 6 1 -- F113 0
1946 RTD #6 high alarm level 1 250 1 °C F1 130
1947 Reserved
1948 RTD #7 high alarm 0 2 1 -- F115 0
1949 RTD #7 high alarm relays 0 6 1 -- F113 0
194A RTD #7 high alarm level 1 250 1 °C F1 80
194B Reserved
194C RTD #8 high alarm 0 2 1 -- F115 0
194D RTD #8 high alarm relays 0 6 1 -- F113 0
194E RTD #8 high alarm level 1 250 1 °C F1 80
194F Reserved
1950 RTD #9 high alarm 0 2 1 -- F115 0
1951 RTD #9 high alarm relays 0 6 1 -- F113 0
Table 7: 469 MEMORY MAP (Sheet 39 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
