58 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
1952 RTD #9 high alarm level 1 250 1 °C F1 80
1953 Reserved
1954 RTD #10 high Alarm 0 2 1 -- F115 0
1955 RTD #10 high alarm relays 0 6 1 -- F113 0
1956 RTD #10 high alarm level 1 250 1 °C F1 80
1957 Reserved
1958 RTD #11 high alarm 0 2 1 -- F115 0
1959 RTD #11 high alarm relays 0 6 1 -- F113 0
195A RTD #11 high alarm level 1 250 1 °C F1 80
195B Reserved
195C RTD #12 high alarm 0 2 1 -- F115 0
195D RTD #12 high alarm relays 0 6 1 -- F113 0
195E RTD #12 high alarm level 1 250 1 °C F1 60
195F Reserved
UNDER
VOLTAGE
1960 Undervoltage active only if bus energized 0 1 1 -- F103 0
1961 Undervoltage alarm 0 2 1 -- F115 0
1962 Undervoltage alarm relays 0 6 1 -- F113 0
1963 Undervoltage alarm pickup 60 99 1 × Rated F3 85
1964 Starting undervoltage alarm pickup 60
100
1
1 × Rated F3 85
1965 Undervoltage alarm delay 0 600 1 s F2 30
1966 Undervoltage alarm events 0 1 1 -- F103 0
1967 Undervoltage trip 0 2 1 -- F115 0
1968 Undervoltage trip relays 0 3 1 -- F111 0
1969 Undervoltage trip pickup 60 99 1 × Rated F3 80
196A Starting undervoltage trip pickup 60
100
1
1 × Rated F3 80
196B Undervoltage trip delay 0 600 1 s F2 30
196C Undervoltage trip mode 0 1 1 -- F149 0
196D Reserved
196E Reserved
... ...
197F Reserved
OVER
VOLTAGE
1980 Overvoltage alarm 0 2 1 -- F115 0
1981 Overvoltage relays 0 6 1 -- F113 0
1982 Overvoltage alarm pickup 101 120 1 × Rated F3 105
1983 Overvoltage alarm delay 5 600 1 s F2 30
1984 Overvoltage alarm events 0 1 1 -- F103 0
1985 Overvoltage trip 0 2 1 -- F115 0
1986 Overvoltage trip relays 0 3 1 -- F111 0
1987 Overvoltage trip pickup 101 120 1 × Rated F3 110
1988 Overvoltage trip delay 5 600 1 s F2 30
1989 Reserved
Table 7: 469 MEMORY MAP (Sheet 40 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
