GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 59
198A Reserved
... ...
199F Reserved
PHASE
REVERSAL
19A0 Voltage phase reversal trip 0 2 1 -- F115 0
19A1 Voltage phase reversal trip relays 0 3 1 -- F111 0
19A2 Reserved
19A3 Reserved
... ...
19AF Reserved
VOLTAGE
FREQUENCY
19B0 Voltage frequency alarm 0 2 1 -- F115 0
19B1 Voltage frequency alarm relays 0 6 1 -- F113 0
19B2 Overfrequency alarm level 2501 7000 1 Hz F3 6050
19B3 Underfrequency alarm level 2000 6000 1 Hz F3 5950
19B4 Voltage frequency alarm delay 0 600 1 s F2 10
19B5 Voltage frequency alarm events 0 1 1 -- F103 0
19B6 Voltage frequency trip 0 2 1 -- F115 0
19B7 Voltage frequency trip relays 0 3 1 -- F111 0
19B8 Overfrequency trip level 2501 7000 1 Hz F3 6050
19B9 Underfrequency trip level 2000 6000 1 Hz F3 5950
19BA Voltage Frequency trip delay 0 600 1 s F2 10
19BB Reserved
19BC Reserved
... ...
19CF Reserved
POWER
FACTOR
19D0 Block power factor element from start 0 5000 1 s F1 1
19D1 Power factor alarm 0 2 1 -- F115 0
19D2 Power factor alarm relays 0 6 1 -- F113 0
19D3 Power factor lead alarm level 5 100 1 -- F3 100
19D4 Power factor lag alarm level 5 100 1 -- F3 100
19D5 Power factor alarm delay 2 300 1 s F1 10
19D6 Power factor alarm events 0 1 1 -- F103 0
19D7Power factor trip 021--F1150
19D8 Power factor trip relays 0 3 1 -- F111 0
19D9 Power factor lead trip level 5 100 1 -- F3 100
19DA Power factor lag trip level 5 100 1 -- F3 100
19DB Power factor trip delay 2 300 1 s F1 10
19DC Reserved
19DD Reserved
... ...
19EF Reserved
Table 7: 469 MEMORY MAP (Sheet 41 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
