GE 469

60 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
REACTIVE
POWER
19F0 Block kvar element from start 0 5000 1 s F1 1
19F1 Reactive power alarm 0 2 1 -- F115 0
19F2 Reactive power alarm relays 0 6 1 -- F113 0
19F3 Positive reactive power alarm level 1 25000 1 kvar F1 10
19F4 Negative reactive power alarm level 1 25000 1 kvar F1 10
19F5 Reactive power alarm delay 2 300 1 s F2 10
19F6 Reactive power alarm events 0 1 1 -- F103 0
19F7 Reactive power trip 0 2 1 -- F115 0
19F8 Reactive power trip relays 0 3 1 -- F111 0
19F9 Positive reactive power trip level 1 25000 1 kvar F1 25
19FA Negative reactive power trip level 1 25000 1 kvar F1 25
19FB Reactive power trip delay 2 300 1 s F2 10
19FC Reserved
19FD Reserved
...
1A0F Reserved
UNDER-
POWER
1A10 Block underpower from start 0 15000 1 s F1 0
1A11 Underpower alarm 0 2 1 -- F115 0
1A12 Underpower alarm relays 0 6 1 -- F113 0
1A13 Underpower alarm level 1 25000 1 kW F1 2
1A14 Underpower alarm delay 1 30 1 s F1 1
1A15 Underpower alarm events 0 1 1 -- F103 0
1A16 Underpower trip 0 2 1 -- F115 0
1A17 Underpower trip relays 0 3 1 -- F111 0
1A18 Underpower trip level 1 25000 1 kW F1 1
1A19 Underpower trip delay 1 30 1 s F1 1
1A1A Reserved
1A1B Reserved
... ...
1A1F Reserved
REVERSE
POWER
1A20 Block reverse power from start 0 5000 1 s F1 0
1A21 Reverse power alarm 0 2 1 -- F115 0
1A22 Reverse power alarm relays 0 6 1 -- F113 0
1A23 Reverse power alarm level 1 25000 1 kW F1 1
1A24 Reverse power alarm delay 2 300 1 s F1 10
1A25 Reverse power alarm events 0 1 1 -- F103 0
1A26 Reverse power trip 0 2 1 -- F115 0
1A27 Reverse power trip relays 0 3 1 -- F111 0
1A28 Reverse power trip level 1 25000 1 kW F1 1
1A29 Reverse power trip delay 2 300 1 s F1 10
1A2A Reserved
Table 7: 469 MEMORY MAP (Sheet 42 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
