GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 61
1A2B Reserved
……
1A2F Reserved
TORQUE
SETUP
1A30 Torque metering 0 1 1 -- F126 0
1A31 Stator resistance 1 50000 1 mΩ F26 4
1A32 Pole pairs 2 128 1 -- F1 2
1A33 Torque unit 0 1 1 -- F148 0
1A34 Reserved
1A35 Reserved
……
1A3F Reserved
OVER-
TORQUE
SETUP
1A40 Overtorque alarm 0 2 1 -- F115 0
1A41 Overtorque alarm relays 0 6 1 -- F113 0
1A42 Torque alarm level 10 9999999 1 Nm/ftlb F10 40000
1A44 Torque alarm delay 2 300 1 s F2 10
1A45 Torque alarm events 0 1 1 -- F103 0
1A46 Reserved
1A47 Reserved
... ...
1A7F Reserved
TRIP
COUNTER
1A80 Trip counter alarm 0 2 1 -- F115 0
1A81 Trip counter alarm relays 0 6 1 -- F113 0
1A82 Trip counter alarm level 1 50000 1 -- F1 25
1A83 Trip counter alarm events 0 1 1 -- F103 0
1A84 Reserved
1A85 Reserved
... ...
1A8F Reserved
STARTER
FAILURE
1A90 Starter failure alarm 0 2 1 -- F115 0
1A91 Starter type 0 1 1 -- F125 0
1A92 Starter failure alarm relays 0 6 1 -- F113 0
1A93 Starter failure alarm delay 10 1000 10 ms F1 100
1A94 Supervision of trip coil 0 2 1 -- F142 0
1A95 Starter failure alarm events 0 1 1 -- F103 0
1A96 Reserved
1A97 Reserved
... ...
1ACF Reserved
Table 7: 469 MEMORY MAP (Sheet 43 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
